LED Street Light with Light Sensor
ENSHINE's YX-SL-03 series industrial street lights adopt a die-cast aluminum light body, one-piece die-casting molding, strong corrosion resistance, high-temperature resistance, and good heat dissipation performance
Highlights
- SMD 3030 patch light source
- High-purity aluminum radiator
- High-stability isolated constant current power supply scheme
- Adjustable beam angle: 70° x 140°
- Long lifespan & 3 years warranty
- Light sensor accessories
Specifications
| Wattage | 50W, 100W, 150W, 200W, 250W |
|---|---|
| Voltage | AC 100-265V, 50/60Hz |
| CCT | 3000K-6000K |
| CRI | >70 |
| Efficacy | 90-100 lm/W |
| IP rating | IK08/IP65 |
| Warranty | 3 Years |
Product Details
Description
ENSHINE's YX-SL-03 series industrial street lights adopt a die-cast aluminum light body, one-piece die-casting molding, strong corrosion resistance, high-temperature resistance, and good heat dissipation performance, which can effectively extend the service life of the street light. The light source is made of high-efficiency SMD3030 LED chips, which have a uniform luminous effect, no light decay, and a long service life. Together with the optical lens, the light is soft and comfortable. The lampshade is made of toughened glass with high strength and is not afraid of being hit during transportation.ion.
Enshine's LED outdoor street lamps are environmentally friendly and energy efficient, with a power factor >0.9 and high luminous efficiency. IP65-rated waterproof designs can cope with harsh weather conditions.itions.
In addition, our LED street lights can be equipped with intelligent light sensors with high sensing sensitivity to automatically turn off during the day and light up at night. By using Enshine's LED streetlights with light sensors, you can achieve high-quality, energy-efficient, environmentally friendly lighting while reducing operation and maintenance costs.sts.
Specifications
Model | YX-SL-03 | ||||
Voltage | AC 100-265V, 50/60Hz | ||||
Wattage | 50W | 100W | 150W | 200W | 250W |
Light Effect | 90-100 lm/W | ||||
LED Chip | SMD 3030 | ||||
Color Temperature | 3000K-6000K | ||||
Color Rendering Index | Ra＞70 | ||||
Color Tolerance Adjustment | ≤10SDCM | ||||
Power Factor | PF > 0.90.9 | ||||
Beam Angle | 70°x140° | ||||
IK/IP | IK08/IP65 | ||||
THD | ≤ 15% | ||||
Insulation Grade | Class I | ||||
Surge Protection | 4 KV | ||||
Installs Way | Lamp Post | ||||
Material | Die-cast aluminum + toughened glass | ||||
Product Size (mm) | 424×173×75 | 506×212×74 | 601×227×75 | 655×240×72 | 815×300×81 |
Average Life | 50000 Hrs | ||||
Brand Name | ENSHINE | ||||
Warranty | 3 Years | ||||
Key Features
SMD 3030 patch light source
High-purity aluminum radiator
High-stability isolated constant current power supply scheme
Adjustable beam angle: 70° x 140°
Long lifespan & 3 years warrantyanty
Light sensor accessories
Application Areas
Specially built for city road lighting, it is widely applicable to city fast roads, main roads, secondary roads, industrial factory roads, highways, garden plots, and other lighting places.
